Chapter 8 Logic Instructions
8-213
8_
Parameter name Function Data type
Valid range
(Default)
Validation timing
FALSE to TRUE.
LinkKeeptime
Set the period of time for
the connection（s）.
UINT
65535
（0）
When Execute
changes from
FALSE to TRUE.
Note:
1. The input parameters RemoteIP_segment1, RemoteIP_segment2, RemoteIP_segment3 and
RemoteIP_segment4 respectively represent the first segment to the fourth segment of the target IP address.
For example, if the target IP is 192.168.1.10, the input value of SlaveIP_segment1 is 192,
SlaveIP_segment2 is 168, SlaveIP_segment3 is 1 and SlaveIP_segment4 is 10.
2. The parameter LinkKeeptime means the duration time of connection with the unit of seconds. When there
is no data transmission for the built link within the period of time, the controller will automatically abort the
connection.
 Output Parameters
Parameter
name
Function Data type Valid range
Done
TRUE when the configuration of parameters is
completed.
BOOL TRUE/FALSE
Busy
TRUE when the instruction is being executed.
BOOL
TRUE/FALSE
Error
TRUE when an error occurs in the instruction execution.
BOOL
TRUE/FALSE
ErrorID
Contains error codes when an error occurs in the
instruction execution. Please refer to section 12.2 for the
corresponding error code.
WORD
 Output Update Timing
Parameter
Name
Timing for changing to TRUE Timing for changing to FALSE
Done
 When the configuration of
parameters is completed.
 When Execute changes from TRUE
to FALSE.
Busy
 When Execute changes to TRUE.
 When Done changes from FALSE to
TRUE.
Error

When input parameters of the
instruction are illegal.
 When Execute changes from TRUE
to FALSE.
