DVP-15MC Series Motion Controller Operation Manual
8-228
Output Update Timing
Timing for changing to TRUE Timing for changing to FALSE
Valid
When Enable changes from FALSE to
TRUE.
When Enable changes from TRUE to
FALSE.
Connected
When Socket link is finished.
When Enable changes from TRUE to
FALSE.
When Closing changes from FALSE to
TRUE.
Received
When a piece of message receiving is
completed.
When Receiving changes from FALSE
to TRUE.
When Enable changes from TRUE to
Closed
When Socket link is closed.
When Enable changes from TRUE to
FALSE.
When Opening changes from FALSE to
Send
When a piece of message sending is
completed.
When Enable changes from TRUE to
FALSE.
When Sending changes from TRUE to
Opening
When the controller starts to build the
Socket link or is waiting to be linked to.
When Enable changes from TRUE to
FALSE.
When Connected changes from FALSE
Receiving
When the controller is receiving a piece
of message.
When Enable changes from TRUE to
FALSE.
When Received changes from FALSE
Closing
When Socket is disabled
When Enable changes from TRUE to
FALSE.
When Closed changes from FALSE to
Sending
When a piece of message is being sent.
When Enable changes from TRUE to
FALSE.
Error
When an instruction execution error or
When Enable changes from TRUE to
To Next Page
