DVP-15MC Series Motion Controller Operation Manual
11-34
name Timing for changing to TRUE Timing for changing to FALSE
When the deceleration ends and the
axis speed is decreased to 0.
When Execute changes from TRUE to
FALSE after the instruction execution is
completed.
Done changes to TRUE when the
instruction execution is completed after
Execute changes from TRUE to FALSE
during the instruction execution. One
period later, Done changes to FALSE.
When Execute changes to TRUE.
When Error changes to TRUE.
When CommandAborted changes to
TRUE.
When Done changes from TRUE to
When the instruction starts to control
the axis.
Error
When CommandAborted changes to
TRUE.
When Done changes from TRUE to
FALSE.
When the instruction execution is
aborted by another MC_Stop.
When Execute changes from TRUE to
FALSE.
CommandAborted changes to TRUE
when the instruction is aborted by
another MC_Stop after Execute changes
from TRUE to FALSE during the
instruction execution. One period later,
CommandAborted changes to FALSE.
When an error occurs in the instruction
execution or the input parameters for
the instruction are illegal.
Execute
FALSE
