Field name Field character
ASCII code corresponding to field
character
LRC check code: 16#F5
“F” 46
“5” 35
End character 1
CR 0D
End character 0
LF 0A
 LRC check (Check sum)
LRC check code is the value by firstly getting the inverse values of every bit of the result value of
addition operation of the data from communication ID to the last data content (Hex.) and then
adding 1 to the final inverse value.
For instance, LRC check code value: 16#FA. The method of calculating LRC check code value:
16#01+ 16#03 + 16#00 + 16#00 + 16#00 + 16#02 = 16#06, the result 16#FA is got by getting the
inverse values of every bit of 16#06 and then adding 1 to the final inverse value.
Field name Field character
ASCII code corresponding to field
character
Start character
“：”
3A
Communication address:
01
“0” 30
“1” 31
Function code: 03
“0” 30
“3” 33
Start data address:
16#0000
“0” 30
“0” 30
“0” 30
“0” 30
Data number (Counted
by word):2
“0” 30
“0” 30
“0” 30
“2” 32
LRC check code: 16#FA
“F” 46
“A” 41
End character 1: CR
CR 0D
End character 0: LF
LF 0A
