TC Troubleshooting
Doc. 065031-04 1/08 233
This error occurs if there is a discrepancy between the TC properties and the
actual configuration.
To troubleshoot:
1. Start the Server Configuration program.
2. In the timebase, right-click the TC and select Properties on the context
menu.
3. Correct any discrepancies in the Properties dialog box.
This error occurs if the current flow rate exceeds the value specified by the
Column_x.FlowRate_UpperLimit command.
To troubleshoot:
Select a valid flow rate.
This error occurs if the current pressure reading is outside the range specified
by the Column_x.Pressure_UpperLimit and Column_x.Pressure_
LowerLimit commands.
To troubleshoot:
Find and eliminate any liquid leaks or blockages in tubing connections (see
Section 8.31
). Adjust the flow rate accordingly.
Configuration doesn’t match. X not installed.
-or-
Configuration mismatch (x - CM uses y, Column
Compartment uses z). Please use the Server Configuration
program to check the installation.
Current flow is out of limits defined for the column.
Current pressure is out of limits defined for the column.
