ICS-3000 Ion Chromatography System
26 Doc. 065031-04 1/08
turn off the pump, press and hold the POWER button for
2 seconds.
The fuse cartridge contains two 2-amp IEC 60127-2 slow-blow fuses
(P/N 954773). For instructions on how to change the fuses, see Section 9.9
.
The power cord plugs into the IEC 320 three-prong receptacle.
Digital I/O Port
The digital I/O port provides a connection to an AS40 Automated Sampler or
other auxiliary device. The connector includes three TTL inputs and four relay
outputs. Table 2-1
indicates the functions assigned to the connector pins.
For instructions on connecting the pump to an AS40, refer to the ICS-3000 Ion
Chromatography System Installation Instructions (Document No. 065032). The
manual is included on the Dionex Reference Library CD-ROM (P/N 053891).
The power supply cord is used as the main disconnect device. Make
sure the socket-outlet is located near the DC and is easily accessible.
Le cordon d'alimentation principal est utilisé comme dispositif
principal de débranchement. Veillez à ce que la prise de base soit
située/installée près du module et facilement accessible.
Das Netzkabel ist das wichtigste Mittel zur Stromunterbrechung.
Stellen Sie sicher, daß sich die Steckdose nahe am Gerät befindet und
leicht zugänglich ist.
The maximum switching voltage of the relays is 24 V. The switching
current must not exceed 100 mA.
Pin Number Signal Name Signal Level Description
1 ----- ----- Not used
2 ----- ----- Not used
3 Relay 3 Out Potential-free Normally open
4 Relay 1 Out Potential-free Normally closed
5 Relay 2 Out Potential-free Normally closed
6 Relay 3 Out Potential-free Normally closed
Table 2-1. 25-Pin D-Sub I/O Port (Female)
