2 • DP/SP Description
Doc. 065031-04 1/08 27
Analog Pressure Output
The analog pressure output indicates the operating pressure of the pump. The
pressure output is set to 50 mV/MPa (5 mV/14.51 psi). To monitor the pressure,
connect the pressure output to a recorder or an A/D converter. These are the pin
assignments for the 2-pin Cinch connector (P/N 8005.9001A):
7 Relay 1 Out Potential-free Common
8 Relay 2 Out Potential-free Common
9 Gnd Ground Ground
10 Gnd Ground Ground
11 Gnd Ground Ground
12 Gnd Ground Ground
13 ----- ----- Not used
14 Relay 4 Out Potential-free Normally open
15 Relay 4 Out Potential-free Common
16 Relay 4 Out Potential-free Normally closed
17 ----- ----- Not used
18 Relay 3 Out Potential-free Common
19 Relay 1 Out Potential-free Normally open
20 Relay 2 Out Potential-free Normally open
21 Vcc Out +5V +5V, 500 mA
22 TTL Input 1 TTL Hold/Run
23 TTL Input 2 TTL Stop
24 TTL Input 3 TTL Start
25 ----- ----- Not used
Signal Level Function
Inner ring: Signal (pressure)
Outer ring: Ground
Pin Number Signal Name Signal Level Description
Table 2-1. 25-Pin D-Sub I/O Port (Female) (Continued)
