Chapter 2
| Using the Web Interface
Navigating the Web Browser Interface
– 69 –
Show Remote Device Information 407
Port/Trunk Displays information about a remote device connected to a port on this
switch
407
Port/Trunk Details Displays detailed information about a remote device connected to this
switch
407
Show Device Statistics 415
General Displays statistics for all connected remote devices 415
Port/Trunk Displays statistics for remote devices on a selected port or trunk 415
PoE
*
Power over Ethernet 417
PSE Configures port power parameters 417
SNMP Simple Network Management Protocol 420
Configure Global Enables SNMP agent status, and sets related trap functions 422
Configure Engine 423
Set Engine ID Sets the SNMP v3 engine ID on this switch 423
Add Remote Engine Sets the SNMP v3 engine ID for a remote device 424
Show Remote Engine Shows configured engine ID for remote devices 424
Configure View 425
Add View Adds an SNMP v3 view of the OID MIB 425
Show View Shows configured SNMP v3 views 425
Add OID Subtree Specifies a part of the subtree for the selected view 425
Show OID Subtree Shows the subtrees assigned to each view 425
Configure Group 428
Add Adds a group with access policies for assigned users 428
Show Shows configured groups and access policies 428
Configure User
Add Community Configures community strings and access mode 433
Show Community Shows community strings and access mode 433
Add SNMPv3 Local User Configures SNMPv3 users on this switch 435
Show SNMPv3 Local User Shows SNMPv3 users configured on this switch 435
Change SNMPv3 Local User Group Assign a local user to a new group 435
Add SNMPv3 Remote User Configures SNMPv3 users from a remote device 437
Show SNMPv3 Remote User Shows SNMPv3 users set from a remote device 435
Configure Trap 440
Add Configures trap managers to receive messages on key events that occur
on this switch
440
Show Shows configured trap managers 440
Table 4: Switch Main Menu (Continued)
Menu Description Page
