Chapter 16
| IP Services
Configuring the PPPoE Intermediate Agent
– 664 –
Parameters
These parameters are displayed:
◆ PPPoE IA Global Status – Enables the PPPoE Intermediate Agent globally on
the switch. (Default: Disabled)
Note that PPPoE IA must be enabled globally before it can be enabled on an
interface.
◆ Access Node Identifier – String identifying this switch as an PPPoE IA to the
PPPoE server. (Range: 1-48 ASCII characters: Default: IP address of first IPv4
interface on the switch.)
The switch uses the access-node-identifier to generate the circuit-id for PPPoE
discovery stage packets sent to the BRAS, but does not modify the source or
destination MAC address of these PPPoE discovery packets. These messages are
forwarded to all trusted ports designated on the Configure Interface page.
◆ Operational Access Node Identifier – The configured access node identifier.
◆ Generic Error Message – An error message notifying the sender that the
PPPoE Discovery packet was too large. (Range: 0-127; Default: PPPoE Discover
packet too large to process. Try reducing the number of tags added.)
◆ Operational Generic Error Message – The configured generic error message.
Web Interface
To configure global settings for PPPoE IA:
1. Click IP Service, PPPoE Intermediate Agent.
2. Select Configure Global from the Step list.
3. Enable the PPPoE IA on the switch, set the access node identifier, and set the
generic error message.
4. Click Apply.
Figure 437: Configuring Global Settings for PPPoE Intermediate Agent
