Chapter 17
| General IP Routing
Address Resolution Protocol
– 680 –
Displaying Dynamic
or Local ARP Entries
Use the IP > ARP (Show Information) page to display dynamic or local entries in the
ARP cache
.
The ARP cache contains static entries, and entries for local interfaces,
including subnet, host, and broadcast addresses. However, most entries will be
dynamically learned through replies to broadcast
messages.
Web Interface
To display all dynamic and local entries in the ARP cache:
1. Click IP, ARP.
2. Select Show Information from the Step List.
3. Click ARP Addresses.
Figure 447: Displaying ARP Entries
Displaying
ARP Statistics
Use the IP > ARP (Show Information) page to display statistics for ARP messages
crossing all interfaces on this router.
Parameters
These parameters are displayed:
Web Interface
To display ARP statistics:
1. Click IP, ARP.
2. Select Show Information from the Step List.
Table 41: ARP Statistics
Parameter Description
Received Request Number of ARP Request packets received by the router.
Received Reply Number of ARP Reply packets received by the router.
Sent Request Number of ARP Request packets sent by the router.
Sent Reply Number of ARP Reply packets sent by the router.
