How to Connect to SFP/SFP+ Fiber Optic Ports
– 46 –
How to Connect to SFP/SFP+ Fiber Optic Ports
The switch provides slots for SFP+ or SFP-compliant fiber-optic transceivers. Note
that all 10G SFP+ fiber optic ports operate at 10 Gbps full duplex. All 1000BASE
fiber optic ports operate at 1 Gbps full duplex.
Note: The length of fiber optic cable for a single switched link should not exceed
the relevant standards specified in this section. However, power budget constraints
should also be considered when calculating the maximum fiber optic cable length
for a particular link.
Note: Maximum distances may vary for different SFP/SFP+ vendors.
Table 9: Maximum 10 Gigabit Ethernet Fiber Cable Lengths
Fiber Size Fiber Bandwidth Maximum Cable Length Connector
10GBASE-SR
62.5/125 micron multimode 160 MHz/km 2-26 m (7-85 ft.) LC
62.5/125 micron multimode 200 MHz/km 2-33 m (7-108 ft.) LC
50/125 micron multimode 400 MHz/km 2-66 m (7-216 ft.) LC
50/125 micron multimode 500 MHz/km 2-82 m (7-269 ft.) LC
50/125 micron multimode 2000 MHz/km 2-300 m (7-984 ft.) LC
10GBASE-LR
9/125 micron single-mode N/A 2 m - 10 km (7 ft - 6.2 miles) LC
10GBASE-ER
9/125 micron single-mode N/A 2 m - 40 km (7 ft - 24.8 miles) LC
Table 10: Maximum Gigabit Ethernet Fiber Cable Lengths
Cable Type Fiber Bandwidth Maximum Cable Length Connector
1000BASE-SX
62.5/125 micron multimode 160 MHz/km 2-220 m (7-722 ft) LC
200 MHz/km 2-275 m (7-902 ft) LC
50/125 micron multimode 400 MHz/km 2-500 m (7-1641 ft) LC
500 MHz/km 2-550 m (7-1805 ft) LC
1000BASE-LX
9/125 micron single-mode N/A 2 m - 10 km (7 ft - 6.2 miles) LC
1000BASE-ZX
9/125 micron single-mode N/A 2 m - 70 km (7 ft - 43.5 miles) LC
