Quick Start Guide
– 6 –
Hardware Specifications
Item Specification
Chassis Specifications
SIze (W x D x H) ECS4620-28T/P/F: 44.0 x 31.5 x 4.4 cm (17.3 x 12.4 x 1.7 in.)
ECS4620-52T/P: 44.0 x 39.1 x 4.4 cm (17.3 x 15.4 x 1.7 in.)
Weight ECS4620-28T: 3.7 kg (8.16 lb)
ECS4620-28P: 4.5 kg (9.92 lb)
ECS4620-28F: 3.8 kg (8.38 lb)
ECS4620-52T: 4.8 kg (10.58 lb)
ECS4620-52P: 6.58 kg (14.51 lb)
Temperature Operating: 0° C to 45° C (32° F to 113° F)
Storage: -40° C to 70° C (-40° F to 158° F)
Humidity Operating: 10% to 90% (non-condensing)
Power Specifications
*
* Maximum power consumption values are measured under a 100 percent loading test and
should be used as estimates for planning purposes.
AC Input Power ECS4620-28T: 100 to 240 V, 50-60 Hz, 1.5 A
ECS4620-28P: 100 to 240 V, 50-60 Hz, 10 A
ECS4620-28F: 100 to 240 V, 50-60 Hz, 2 A
ECS4620-52T: 100-240 VAC, 50-60 Hz, 2 A
ECS4620-52P: 50-60 Hz
100 to 127 VAC, 12 A
200 to 240 VAC, 6 A
Power Consumption ECS4620-28T: 40 W max. (with one expansion module)
ECS4620-28P: 501 W max. (with one expansion module)
ECS4620-28F: 50 W max. (with one expansion module)
ECS4620-52T: 70 W (with one expansion module)
ECS4620-52P: 960 W (with one expansion module and PoE enabled)
ECS4620-52P maximum power consumption is reduced to 780 W when
the device is powered from a connected RPS.
Redundant Power Supply (This accessory and specifications only apply to the ECS4620-52P.)
Input Power 100-240 VAC, 50-60 Hz, 12 A
Output Power 12 VDC, 10 A
-54.5 VDC, 14.3 A
Regulatory Compliances
Emissions CE Mark
◆
EN 55022, Class A
FCC Class A
EN 61000-3-2/3
VCCI Class A
Immunity EN 61000-4-2/3/4/5/6/8/11
Safety UL 60950-1 & CSA 60950-1
IEC 60950-1 & EN 60950-1
ECS4620-28F:
UL/CUL (CSA 22.2 NO 60950-1 & UL 60950-1)
CB (IEC/EN60950-1)
