Chapter 13
| Basic Administration Protocols
Link Layer Discovery Protocol
– 402 –
â—† Any number of CA type and value pairs can be specified for the civic address
location, as long as the total does not exceed 250 characters.
Parameters
These parameters are displayed:
◆ CA-Type – Descriptor of the data civic address value. (Range: 0-255)
◆ CA-Value – Description of a location. (Range: 1-32 characters)
Web Interface
To specify the physical location of the attached device:
1. Click Administration, LLDP.
2. Select Configure Interface from the Step list.
3. Select Add CA-Type from the Action list.
4. Select an interface from the Port or Trunk list.
5. Specify a CA-Type and CA-Value pair.
6. Click Apply.
Figure 243: Configuring the Civic Address for an LLDP Interface
21 Landmark or vanity address Tech Center
26 Unit (apartment, suite) Apt 519
27 Floor 5
28 Room 509B
Table 23: LLDP MED Location CA Types (Continued)
CA Type Description CA Value Example
