– 11 –
1 Switch Description
This chapter includes these sections:
◆ “Overview” on page 11
◆ “Key Technical Specifications” on page 15
Overview
The ECS4620-28T, ECS4620-28T-DC, ECS4620-28P, ECS4620-52T, and ECS4620-52P
are Gigabit Ethernet Layer 3 stackable switches with 24/48 10/100/1000BASE-T
ports, two 10-Gigabit (10G) Small Form Factor Pluggable Plus (SFP+) transceiver
slots. The ECS4620-28F and ECS4620-28F-DC are Layer 3 switches that provid 22
SFP 1G transceiver slots, two combination Gigabit RJ-45/SFP ports, and two 10G
SFP+ slots. The ECS4620-28P and ECS4620-52P front-panel ports also support
Power-over-Ethernet Plus (PoE+).
All switches also provide one rear-panel slot for a dual-port 10G hot-swappable
expansion module.
The switches include an SNMP-based management agent, which provides both in-
band and out-of-band access for managing the switch. Further, the switches
support both web and CLI-based configuration.
These switches include built-in stacking ports that enable up to eight units to be
connected together through a 40 Gbps stack backplane. The switch stack can be
managed from a master unit using a single IP address.
Power-over-Ethernet All of the 10/100/1000 Mbps ports on the ECS4620-28P and ECS4620-52P support
the IEEE 802.3at Power-over-Ethernet Plus (PoE+) standard that enables DC power
to be supplied to attached devices using wires in the connecting Ethernet cable.
