FOR RESTRICTED USE only Fargo Electronics, Inc.
DTC550 Direct to Card Printer/Encoder User Guide (Rev. 2.8)
5-5
Adjusting the Card Guide Rail (continued)
Step Procedure
5 If the PolyGuard patch is being placed more toward a card's bottom edge
(as shown), move the Card Guide Rail slightly toward the front of the
Printer (opposite the direction you would like the patch to move).
6 Always make very slight adjustments to the Card Guide Rail and run a test
print after each adjustment until the optimum patch position is found.
(Note: Be sure the Card Guide Rail always remains parallel to the card
path and that the screws loosened in step 3 are retightened after each
adjustment.)
