Printer Components: LCD and Softkey Control Pad
The Printer provides a four line, eighty (80) character LCD display that communicates helpful
information about the Printer's operation.
• The top three lines of the LCD display will always be used to communicate print status,
error messages and menu options.
• The bottom line of the LCD display will always be used to communicate the current
function of the Printer's softkey buttons.
This section describes how the LCD display and Softkey Control Pad work together.
Component Description
Softkey
Buttons
The Printer has three softkey buttons that appear below the LCD
display. (Note: Their current function is indicated by the words
appearing above them. This function will change according to the
Printer's current mode of operation.)
Press the corresponding softkey button for the correct selection.
(Note: If no word appears above a particular button, this indicates
it has no function in that particular mode of operation.)
Use the scroll buttons to scroll through help text
, to navigate
through the Printer's menus
and to adjust certain Printer settings.
(Note: The Printer has scroll buttons on its control pad located just
to the right of the LCD display.)
If scrolling through a list, this symbol will change to if you have
reached the bottom of the list or
if you have reached the top.
LCD display The Printer's LCD display will change according to the Printer's
current mode of operation.
System
Check
Screens
When the Printer is first powered ON, the Printer's system check
screens will briefly appear to:
Initialize the system.
Display the READY screen.
