FOR RESTRICTED USE only Fargo Electronics, Inc.
DTC550 Direct to Card Printer/Encoder User Guide (Rev. 2.8)
6-2
Selecting the Card Size
Select either CR-80 or CR-79 for the appropriate card size option from the two (2)
standard card sizes.
When designing a card format, always set the card size or page size within the card
design program to the exact Print Length and Width dimensions listed in the Printer
Driver.
The dimensions of the total print area for each card size will appear in the Print Width
and Print Length boxes.
Step Procedure
1 Select CR-80 to print onto standard "credit card" sized cards.
OR
Select CR-79 to print onto slightly smaller CR-79 sized cards (3.303” L x
2.051W/83.9mm L x 52.1mm W). (Note: The CR-79 card adhesive-backed
card is used in applications where they are printed and applied to thicker
proximity cards.)
2 Select either the inches or mm radio button (as needed).
