FOR RESTRICTED USE only Fargo Electronics, Inc.
DTC550 Direct to Card Printer/Encoder User Guide (Rev. 2.8)
2-28
Reviewing the Lamination Top Cover and Station
Component Description
Lamination
Top Cover
Opens to allow access to the Lamination Station, overlaminate and
card path.
Lamination
Station
Transfers overlaminates onto cards via its heated lamination roller.
The Lamination Station must be closed in order for the Printer to begin
laminating.
Lamination
Top Cover
Securing
Latches
Lamination Station
Lamination
LED Light
Cancel
Button
Resume
(pause) Button
Rejection
Card Hopper
Card Output
Hopper
