Setting the Print EOF
This procedure positions the printed image correctly on the trailing edge of the card.
Step Procedure
1 Choose MENU, Print Test Image and Gray/Align YMC/K to print a test
card.
2 Select MENU, Setup Printer, Print Settings and Print EOF.
3 Record the Print EOF value on the test card you just printed.
4 a. Examine the test card.
b. If the test card does not look like the sample shown below, go to Print
EOF.
5 Decrease the Print EOF value to move the printed image more toward the
leading edge of the card.
OR
Increase the Print EOF value to move the printed image more toward the
trailing edge of the card.
• The numbers being entered for the settings are in ½ pixels.
• The number of pixels is equal to the measurement in inches times 600
or the measurement in mm times 23.6. (For example, 0.100 inches or
2.54mm equals 60 increments on the LCD.)
