Measuring the Total Card area
Step Procedure
1 Determine the area of the card to define. (Note: This area is indicated by the
dashed outline, as shown below. The easiest way to determine the size of this
area is to actually print a card and look at it in the same orientation as when it
exits the Printer.)
2 Measure the total area and enter those dimensions into the Dimension boxes,
as shown below.
