DTC550 Direct to Card Printer/Encoder User Guide (Rev. 2.8)
6-70
Using the Overlay/Print Area dropdown menu
Step Procedure
1
• Select the Full Card option for the Printer to overlay and/or print the
entire card.
OR
• Select the Defined Area(s) option for the Printer to overlay and/or print
only in the selected and defined area or areas.
OR
• Select the Undefined Area(s) option for the Printer to overlay and/or
print only in the space outside the selected and defined area.
OR
• Select the Omit Smart Chip Area option for the Printer to overlay
and/or print only in the space outside the standard location of a smart
chip.
OR
• Select the Omit Mag Stripe Area option for the Printer to overlay
and/or print only in the space outside the standard location of an ISO
Magnetic Stripe.
OR
• Select the Omit Signature Area option for the Printer to overlay and/or
print only in the space outside the standard location of a signature
panel.
(Note: In the card grid, black indicates the area in which the overlay and/or
printing will be applied.)
