Fargo DTC550 - Defining the Area to Activate the Card Grid

FOR RESTRICTED USE only Fargo Electronics, Inc.
DTC550 Direct to Card Printer/Encoder User Guide (Rev. 2.8)
6-90
Defining the Area to activate the Card Grid
Step Procedure
1 Select on the appropriate Defined Area (see below) to activate the card grid
in the upper half of the window. (Note: It is through this card grid that up to
five areas can be defined, as shown below.)
When the card grid is first activated, a small black square will appear at its:
• default size of .2" x .2" (5mm x 5mm)
• default location in the lower left-hand corner (0,0)
(Note: This square represents the first defined area.)
