FOR RESTRICTED USE only Fargo Electronics, Inc.
DTC550 Direct to Card Printer/Encoder User Guide (Rev. 2.8)
11-15
Setting the Print TOF (continued)
Step Procedure
5 Decrease the Print TOF value to move the printed image more toward the
leading edge of the card.
OR
Increase the Print TOF value to move the printed image more toward the
trailing edge of the card.
• The numbers being entered for the settings are in ½ pixels.
• The number of pixels is equal to the measurement in inches times 600
or the measurement in mm times 23.6. (For example, 0.100 inches or
2.54mm equals 60 increments on the LCD.)
6 Press DONE to save the value and print another test card. Press YES
when asked to save the change.
7 Repeat Steps 1 to 6 until the test image is correctly positioned as shown
above.
