FOR RESTRICTED USE only Fargo Electronics, Inc.
DTC550 Direct to Card Printer/Encoder User Guide (Rev. 2.8)
1-8
Reviewing DTC550 Sequence of Operations (continued)
Step Process
20 The Card Feed Motor feeds the Card back to the Print TOF Sensor.
21 Repeat steps 14 to 20 for the appropriate Number of Color/Overlay Panels.
22 The Card Feed Motor transports the Card back to the Flipper Table.
23 The Flipper Stepper rotates in order to invert the Card.
24 The Card Feed Motor activates and moves the card to the Print TOF Sensor.
All Stop.
25 Repeat steps 14 to 20 for the appropriate Number of Color/Overlay Panels if
printing a Dual sided card. If not then card is transported to the laminator if
applicable or ejects the card.
To Next Page
