FOR RESTRICTED USE only Fargo Electronics, Inc.
DTC550 Direct to Card Printer/Encoder User Guide (Rev. 2.8)
6-27
Using the Image Color tab (continued)
Step Procedure
2 Select the None, Monitor or System Color Management option (see the
Device options tab, shown below) to only display the Dye-Sub Intensity,
Resin Heat sliders and Overlay Heat.
3 Control the overall darkness and lightness of the dye-sub printed image by
adjusting the Dye-Sub Intensity slide by clicking and dragging the slide's
box.
• Move the slide to the left to cause less heat to be used in the printing
process, thus generating a lighter print.
OR
• Move the slide to the right to cause more heat to be used, thus
generating a darker print.
(Note: This slide only affects those images printed with Dye-Sublimation
Ribbon panels (YMC).)
