FOR RESTRICTED USE only Fargo Electronics, Inc.
DTC550 Direct to Card Printer/Encoder User Guide (Rev. 2.8)
6-73
Using the Overlay/Print Area (continued)
Step Procedure
2 When the card grid is first activated, a small black square will appear at its
default size of .2" x .2"/5mm x 5mm and at its default location in the lower
left-hand corner (0,0). (Note: This square represents the first defined area.)
Determine the area size by actually printing a card and looking at it in the
same orientation as when it exits the Printer.
3 Measure the total size of the desired area and enter those dimensions into
the Dimension boxes. (Note: The minimum size an area is .2" x .2"/5mm x
5mm.)
