DTC550 Direct to Card Printer/Encoder User Guide (Rev. 2.8)
2-7
Technical Specifications (continued)
Term Description
Print Speed –
Batch Mode
• K: 7 seconds per card/514 cards per hour*
• BO: 12 seconds per card/300 cards per hour*
• YMCKO: 25 seconds per card/144 cards per hour*
• YMCKOK: 33 seconds per card/109 cards per hour*
• YMCKK (w/Lamination): 35 seconds per card /102 cards
per hour*
Indicates the Print Ribbon type and the number of Ribbon panels
printed where Y=Yellow, M=Magenta, C=Cyan, K=Resin Black,
B=Dye-Sublimation Black and O=Overlay.
Print speeds do not include the time needed for the PC to
process the image.
Process time is dependent on the size of the file, the CPU,
amount of RAM and the amount of available resources at the time
of the print.
Print speed indicates an approximate batch print speed and is
measured from the time a card feeds into the Printer to the time it
ejects from the Printer. (Note: The single card print speeds will
be slower than the batch print speeds listed above since batch
print speed is enhanced by the Printer's multi-tasking capabilities
when printing multiple cards in succession.)
Print Ribbon
options
• Full-color with resin black and overlay panel, YMCKO*, 500
prints
• Full-color with two resin black panels and overlay panel,
YMCKOK*, 400 prints
• Full-color with two resin black panels, no overlay panel,
YMCKK*, 500 prints
• Resin black (3000 prints); green, blue, red, white, silver and
gold (1000 prints)
• Resin black and overlay panel, KO*, 1500 prints
