Paper Jams
565
Problem Solving
15
2 Move the lever 1a to the right.
3 Remove the jammed paper.
Note • If paper is torn, check for any torn pieces
of paper inside the machine.
4 Return the lever 1a to the original position.
5 Close the front cover of the finisher.
Note • A message will be displayed and the machine will not operate if the front cover of the finisher
is even slightly open.
Paper Jams at the Lever 1d and the Wheel 1c
1 Open the front cover of the finisher.
2 Move the lever 1d to the left, and then move
the lever 6 upward.
3 Turn the wheel 1c to the direction indicated
by the arrow, and then remove the jammed
paper.
Note • If paper is torn, check for any torn pieces
of paper inside the machine.
To Next Page
