15 Problem Solving
590
Problem Solving
15
Staple Jams in the Staple Cartridge for Finisher C2 or Finisher C2 with
Booklet Maker
The following describes how to clear staple jams in the staple cartridge when the
Finisher C2 (optional) or the Finisher C2 with Booklet Maker (optional) is installed.
The following example shows how to clear paper jams in the Finisher C2 with Booklet
Maker. The procedure is the same as for the Finisher C2.
1 Make sure that the machine has stopped
before opening the front cover of the finisher.
2 Grip the lever R1 of the staple cartridge
holder, and pull out the holder to the right
towards you.
3 Remove the staple cartridge holder by
gripping the orange lever.
Note • The staple cartridge is firmly held. When
removing the staple cartridge, strongly
pull the cartridge.
4 After removing the staple cartridge, check
the inside of the finisher for any remaining
staples.
CAUTION
Be careful in removing jammed staples.
To Next Page
