Staple Cartridge Taken Off from Unit for the Finisher D2-P with Booklet Maker
595
Problem Solving
15
Staple Cartridge Taken Off from Unit for the Finisher D2-P with
Booklet Maker
The following describes how to set the staple cartridge to its unit when it has been
attached incorrectly or taken off from its unit accidentally.
1 Open the staple cartridge cover as shown in
the figure, and remove the jammed staple.
2 See a lever on the rear side of the unit.
3 Move the lever in the direction of the arrow
shown in the figure.
Important • Be careful when removing jammed
staples to avoid hurting your fingers and
nails.
4 Turn the unit upside holding the lever, and
then take off the staple cartridge from its unit.
CAUTION
Be careful when removing jammed staples.
To Next Page
