Stapler Faults
593
Problem Solving
15
If the staples cannot be removed after carrying out the above procedures, contact our
Customer Support Center.
Staple Jams in the Staple Cartridge for the Finisher D2-P with Booklet
Maker
The following describes how to clear staple jams in the staple cartridge when the
Finisher D2-P with Booklet Maker (optional) is installed.
1 Make sure that the machine has stopped
before opening the right cover of the finisher.
2 Hold the R1 at the position shown in the
figure.
3 Pull out the unit.
Note • After removing the unit, check the inside
of the finisher for any remaining staples.
4 Open the unit as shown in the figure and
remove the jammed staple.
CAUTION
Be careful in removing jammed
staples.
To Next Page
