15 Problem Solving
562
Problem Solving
15
Paper Jams in the Bottom Left Cover
The following describes how to clear paper jams in the bottom left cover.
1 If Tray 6 (HCF2 (2000 sheets)) is installed,
gently move Tray 6 to the left until it stops by
gripping the handle on the top left side of
Tray 6.
2 Open the bottom left cover while gripping the
release lever.
3 Remove the upper jammed paper.
Note • If paper is torn, check for any torn pieces
of paper inside the machine.
4 Remove the lower jammed paper.
Note • If paper is torn, check for any torn pieces
of paper inside the machine.
5 Close the bottom left cover.
Note • A message will be displayed and the machine will not operate if the bottom left cover is even
slightly open.
6 If Tray 6 (HCF2 (2000 sheets)) is installed, push the tray in gently until it comes to a
stop.
To Next Page
