HP-GL/2 Emulation
669
Appendix
16
Paper Margin
The paper size is set to A sizes by factory default. If the print data is larger than the
active coordinates area, the machine prints the data on the next larger A series paper
(for example, the next larger size of A4 is A3).
When you set the paper margins, however, the active coordinates area is determined
by subtracting the area set in paper margins from the active coordinates area obtained
in the area determination mode. Therefore, set the paper margins if the data is printed
on larger paper than specified. Set the range from 0 to 99 mm. The default value is 0
mm.
HP-GL/2 Emulation Settings
The following table shows the emulation parameters and their values for HP-GL/2
emulation.
HP-GL Settings List
Items that can be set using the HP-GL mode menu are explained in two groups: basic
settings and extended settings.
Basic Settings
Parameter Item No. Value
Document size 101 Sets the document size created by a computer.
[0] : A0
[1] : A1
[2] : A2
[3] : A3
[4] : A4
[5] : A5
[10] : B0
[11] : B1
[12] : B2
[13] : B3
[14] : B4
[15] : B5
[99] (Default) : Auto
[100] : Paper
When [Auto] is selected, the settings of the Scaling mode, the Area
Determination mode, and the Paper Margin settings of Print Control
become enabled.
Note • If the document size other than [Auto] is selected, the settings under
[Auto layout] become [ON].
• Depending on the combination of [Document size] and [Paper size],
the document is printed at a scale of 100%.
To Next Page
