3 Maintenance
84
Maintenance
3
Replacing the Staple Cartridge for Finisher C2 or Finisher C2 with
Booklet Maker
When the Finisher C2 (optional) or the Finisher C2 with Booklet Maker (optional) is
installed and it is time to replace the staple cartridge, a message appears on the touch
screen. When this message appears, replace the staple cartridge with a new one.
This section explains how to replace the staple cartridge in the Finisher C2 with Booklet
Maker. Use the same procedures for the Finisher C2.
Important • The use of staple cartridges not recommended by Fuji Xerox may impair quality and
performance. Use only staple cartridges recommended by Fuji Xerox for the machine.
Note • If the staple cartridge was not replaced properly, the message remains on the touch screen.
Follow the procedure and replace the staple cartridge again.
• To order a staple cartridge, contact our Customer Support Center.
1 Make sure that the machine has stopped,
and open the front cover of the finisher.
2 Grip the lever R1 of the staple cartridge
holder, and pull out the holder to the right
towards you.
3 Remove the staple cartridge holder by
gripping the orange lever.
Note • The staple cartridge is firmly held. When
remove the staple cartridge, strongly pull
the cartridge.
4 Pick the empty staple case with your fingers
(1), and then remove the case from the
cartridge (2) as shown in the figure.
1
2
1
To Next Page
