Replacing Consumables
85
Maintenance
3
5 Prepare a new staple case. Insert the front of
the staple case into the staple cartridge (1),
and push the rear of the case to set (2).
6 Hold the orange lever to push the staple
cartridge into the machine until it clicks into
place.
7 Close the front cover of the finisher.
Note • A message will be displayed and the machine will not operate if the front cover of the finisher
is even slightly open.
Replacing the Booklet Staple Cartridge
(Finisher C2 with Booklet Maker or Finisher D2-P with Booklet Maker)
When the Finisher C2 with Booklet Maker (optional) or the Finisher D2-P with Booklet
Maker (optional) is installed and it is time to replace the booklet staple cartridge, a
message appears on the touch screen. When this message appears, replace the
staple cartridge with a new one.
This section explains how to replace the staple cartridge in the Finisher C2 with Booklet
Maker. Use the same procedures for the Finisher D2-P with Booklet Maker.
Important • The use of staple cartridges not recommended by Fuji Xerox may impair quality and
performance. Use only staple cartridges recommended by Fuji Xerox for the machine.
Note • If the staple cartridge was not replaced properly, the message remains on the touch screen.
Follow the procedure and replace the staple cartridge again.
• To order a staple cartridge, contact our Customer Support Center.
1 Make sure that the machine has stopped,
and open the front cover of the finisher.
1
2
To Next Page
