Stapler Faults
591
Problem Solving
15
5 Pull up the metal part of the staple cartridge
shown in the figure.
6 Remove the jammed staples (1), and return
the metal part pulled up in step 5 to the
original position (2).
7 Insert the staple cartridge while gripping the
orange lever until it clicks into place.
8 Close the front cover of the finisher.
Note • A message will be displayed and the machine will not operate if the front cover of the finisher
is even slightly open.
If the staples cannot be removed after carrying out the above procedures, contact our
Customer Support Center.
Staple Jams in the Booklet Staple Cartridge for the Finisher C2 with
Booklet Maker or Finisher D2-P with Booklet Maker
The following describes how to clear staple jams in the booklet staple cartridge when
the Finisher C2 with Booklet Maker (optional) or the Finisher D2-P with Booklet Maker
(optional) is installed.
The following example shows how to clear paper jams in the Finisher C2 with Booklet
Maker. The procedure is the same as for the Finisher D2-P with Booklet Maker.
1 Make sure that the machine has stopped
before opening the front cover of the finisher.
1
2
To Next Page
