16 Appendix
674
Appendix
16
Folding/180
degree rotation
168 Specify the Z fold half sheet and whether to rotate landscape documents
in 180 degrees.
[0] (Default) : None
[1] : Z fold half sheet (Right bind/Top bind)
[2] : Z fold half sheet (Right bind/Bottom bind)
[3] : None (180 degrees rotation)
[4] : Z fold half sheet (Right bind/Top bind, 180 degrees
rotation)
[5] : Z fold half sheet (Left bind/Bottom bind, 180 degrees
rotation)
Emulation target
printer
169 Select the machine to emulate.
[0] (Default) : HP750
[1]1 : FX4036
Pen attributes 800-815 (Pen
width)
(No. 0-No.15)
Set the width (thickness of the line) of the 16 pens (No. 00 to 15). You can
set the width from 0.0 to 25.5 mm in 0.1 mm increments. No. 00 denotes
Item No. 800.
[0] - [255] (Default: 3) : 0 to 25.5 mm
Note • If the image is reduced by concern with the relationship between
[Document size] and [Paper size] settings, the pen width is reduced
accordingly to 0.1 mm at the smallest.
• The width of the line gets thick symmetrically with respect to the
center of the line.
• If the width is set to 0.0 mm, nothing is plotted.
850-865 (Line
end shape)
(No. 0-No.15)
Set the line end shape of the 16 pens (No. 00 to 15). No. 00 denotes Item
No. 850.
[0] (Default) : Cut
[1] : Round
[2] : Rectangular
[Cut]
: specified coordinate
[Round]
: specified coordinate
[Rectangular]
: specified coordinate
Parameter Item No. Value
