Fujitsu Server PRIMERGY TX1330 M1 - Page 313

TX1330 M1 Upgrade and Maintenance Manual 313
Cabling
Figure 214: Removing the intrusion switch cable (B)
Ê Slide back the intrusion switch holder until it disengages from the HDD bay
top cover (1).
Ê Remove the intrusion switch holder (2).
