Navigational Status (Underway using engine, At anchor, Not under
command, Restricted maneuverability, Constrained by her
draught, Moored, Aground, Engaged in fishing, Under way sailing,
Reserved for high speed craft, Reserved for wing in ground,
power-driven vessel towing astern (regional use), power-driven
vessel pusing ahead or towing alongside (regional use), Reserved
for future use, AIS-SART (active), Not defined)
Persons (0 to 8191, 0)
MAX Draught (0.0 to 25.5, 0.0 m)
ETA
Destination
Cargo Category*
1
(All ships of this type, Carrying DG, HS, or
MP, IMO hazard or pollutant category X, Carrying DG, HS, or MP,
IMO hazard or pollutant category Y, Carrying DG, HS, or MP, IMO
hazard or pollutant category Z, Carrying DG, HS, or MP, IMO
hazard or pollutant category OS, Reserved for future use (×4), No
Additional Information)
Log
Chart
Alert
Set WARNING or CAUTION for (Safety Contour*
2
, Navigational Hazard,
Areas To Be Avoided, User Chart Danger, Traffic Separation Zone,
Inshore Traffic Zone, Restricted Area, Caution Area, Offshore Production
Area, Military Practice Area, Seaplane Landing Area, Submarine Transit
Lane, Anchorage Area, Marine Farm / Aqua Culture, PSSA Area, No
Vector Chart, Too Many Dangers, UKC Limit, Sounding UKC Limit,
Non-official ENC, Not Up-to-date, Permit Expired)
Shallow Contour (0-99*
3
,
10 m
)
Safety Depth (0-99,
20 m
)
Safety Contour (0-99,
30 m
)
Deep Contour (0-99,
60 m
)
AIS-CPA
Auto
Activate
Limits
Log Interval (1 to 4, 4 hours)
Distance Counter*
AIS DISP
Filter
Sleep All
Targets
Voyage
data
NAV
Log
Voyage Speed (0 to 10, 5 kn)
Course (0.0 to 30.0, 10.0°)
Target
Log
Danger Target (Log Interval 1 to 100, 10 min)
TT/AIS
Setting
Setting.1 Sleeping Class A (ON, OFF)
Sleeping Class B (ON, OFF)
MAX Range (ON, OFF; 0 to 99 NM, 12 NM)
MIN Ship Speed (ON, OFF; 0.0 to 9.9 kn, 1.0 kn)
MAX Range (ON, OFF; 0 to 99 NM, 0 NM)
MIN Ship Speed (ON, OFF; 0.0 to 9.9 kn, 1.0 kn)
Except Class B (ON, OFF)
Setting.2 AIS Lost
Target
Filter
MAX Range (ON, OFF; 0 to 99 NM, 12 NM)
MIN Ship Speed (ON, OFF; 0.0 to 9.9 kn, 1.0 kn)
Except Class B (ON, OFF)
TT Lost
Target
Filter
MAX Range (ON, OFF; 0 to 99 NM, 12 NM)
NAV
Status
Own Ship (Shows own ship’s MMSI No., Name, Call Sign, Type, Description,
Length, Width, Ref Bow, and Ref Port.)
1
2
(Continued from previous page)
Association
Target
Gap (0.000 to 0.050 NM,
0.050 NM
)
Range (0.000 to 0.100 NM,
0.100 NM
)
Bearing (0.0 to 9.9°,
9.9°
)
Speed (0.0 to 6.0 kn,
6.0 kn
)
Course (0.0 to 25.0°,
25.0°
)
NAV Tools
Geometry
Guide Box (Rhumbline, Great Circle)
EBL/VRM (Rhumbline, Great Circle)
PI Lines (Great Circle)
Rings (Rhumbline, Great Circle)
Divider (Rhumbline, Great Circle)
PI Lines
Truncate
Setting (Set forward and backward lengths of each PI line.)
Shared
Monitoring (Set master and backup units.)
Route Transfer Func. OFF, Func. ON
Storing received route plans (Reject, Overwrite, Ignore)
Odometer
Trip Meter
*: Display only
*
2
: Fixed at Alarm
*
3
: Maximum value defined by
value forSafety Contour
*
1
: May be hidden
depending on AIS
transponder settings.
