FURUNO FCR-21x9-BB, FCR-28x9 SERIES
SP - 5 E3607S01E-M
FCR-2829W
100-115/220-230 VAC: 3.0/1.8 A, 1 phase, 50-60 Hz
7.5 HUB 100-230V AC: 0.1 A max, 1 phase, 50/60 Hz
7.6 S-band antenna
Model Antenna voltage input (at wind speed 100 kn)
200VAC,3ø,50Hz
220VAC,3ø,60Hz
380VAC,3ø,50Hz
440VAC,3ø,60Hz
220VAC,
3ø,50 Hz
(HSC)
220VAC,
3ø,60Hz
(HSC)
440VAC,
3ø,60 Hz
(HSC)
FCR-2139S-BB 3.0A 1.5A 3.5A 3.5A 1.7A
FCR-2839S 3.0A 1.5A 3.5A 3.5A 1.7A
FCR-2839SW 3.0A 1.5A - - -
8 ENVIRONMENTAL CONDITIONS
8.1 Ambient temperature
Antenna unit -25°C to +55°C (storage: -25°C to +70°C)
Others -15°C to +55°C
8.2 Relative humidity 93% or less at +40°C
8.3 Degree of protection
Antenna unit IP56
Processor unit RPU-013: IP20, EC-3000: IP20 (IP22: option)
Transceiver/power supply unit IP20
Control/monitor unit IP22
Sensor adapter IP20 (IP22: option)
HUB HUB-100: IP20, HUB-3000: IP22
8.4 Vibration IEC 60945 Ed.4
9 UNIT COLOR
9.1 Antenna unit N9.5
9.2 Processor/transceiver unit 2.5GY/1.5
9.3 Control unit N3.0
9.4 Monitor unit N2.5
10 PERFORMANCE MONITOR
10.1 PM-31 (X-band)
Frequency 9370 to 9450 MHz
Input power +8 dBm min., +28 dBm max.
Output power -36 dBm (2nd pulse max. output),
-56 dBm (2nd pulse min. output)
Step level 7.5 to 10.5 dB (1st pulse to 2nd pulse)
10.2 PM-51 (S-band)
Frequency 3020 to 3080 MHz
Input power +5 dBm, min., +15 dBm max.
Output power -15 dBm (2nd pulse max. output),
-35 dBm (2nd pulse min. output)
Step level 9.0 to 11.0 dB (1st pulse to 2nd pulse)
