FURUNO
FCR-21x9-BB, FCR-28x9 SERIES
SP - 4 E3607S01E-M
Destination port 60001 to 60016
Re-transmittable binary image transfer
Multicast address 239.192.0.26 to 239.192.0.30
Destination port 60026 to 60030
Other network function excepted IEC6162-450
HTTP: *.*.*.*: 80, XML-RPC: *.*.*.*: 6403
Syslog: 239.190.0.254: 514
6.3 Ethernet interface for IEC61162-450 (MC-3000S)
Port 100Base-TX, IPv4, 8P8C connector
Maximum data rate 800 sps
Data sentences Output: XDR
IEC61162-450 transmission group
Input MISC, TGTD, SATD, NAVD, VDRD, RCOM, TIME, PROP,
USR1 to USR8
Output Arbitrary (default: MISC)
Multicast address 239.192.0.1 to 239.192.0.16
Destination port 60001 to 60016
Re-transmittable binary image transfer
Multicast address 239.192.0.26 to 239.192.0.30
Destination port 60026 to 60030
Other network function excepted IEC6162-450
HTTP: *.*.*.*: 80, XML-RPC: *.*.*.*: 6403
Syslog: 239.190.0.254: 514
6.4 Sensor adapter (option)
MC-3000S (serial) 8 ports: I/O, IEC61162-1/2: 4 ports, IEC61162-1: 4 ports
MC-3010A (analog) 3 ports: Input, -10 to +10 V, 0 to 10 V or 4 to 20 mA
MC-3020D (digital-in) 8 ports: relay contact, logics set from program
MC-3030D (digital-out) 8 ports: relay contact, normal open and normal close available
6.5 Radar processor unit (RPU-013)
Heading signal Sync signal (20-100 VDC or 20-135 VAC, 50/60/400/500 Hz) or
stepper signal (20-100 VDC), built-in interface (option) required,
AD-10 format
7 POWER SUPPLY
7.1 Monitor unit
MU-231 100-230 VAC, 1.0-0.6 A, 1 phase, 50-60 Hz
MU-190 (option) 100-230 VAC, 0.7-0.4 A, 1 phase, 50-60 Hz
7.2 Processor unit (EC-3000) 100-115/220-230 VAC: 1.5-0.7 A, 1 phase, 50-60 Hz
7.3 Sensor adapter 24 VDC: 1.4 A (for 11 units), Input to MC-3000S, the sources of
other sensor adapters are fed from MC-3000S
7.4 Radar processor unit (RPU-013)
FCR-2119-BB/2819
100-115 VAC: 2.6 A (3.0 A), 1 phase, 50-60 Hz
220-230 VAC: 1.6 A (1.7 A), 1 phase, 50-60 Hz
FCR-2129-BB/2829
100-115 VAC: 3.0 A (3.4 A), 1 phase, 50-60 Hz
220-230 VAC: 1.8 A (1.9 A), 1 phase, 50-60 Hz ( ): 42 rpm
FCR-2139S-BB/2839S/2839SW
100-115/220-230 VAC: 2.6/1.6 A, 1 phase, 50-60 Hz
