CHAPTER 7: PROTECTION GROUPED PROTECTION ELEMENTS
D90
PLUS
LINE DISTANCE PROTECTION SYSTEM – INSTRUCTION MANUAL 221
Figure 195: Load encroachment characteristic
The element operates if the positive-sequence voltage is above a user-specified level and
asserts its output signal that can be used to block selected protection elements, such as
distance or phase overcurrent. The following figure shows an effect of the load
encroachment characteristics used to block the quadrilateral distance element.
Figure 196: Load encroachment applied to distance element
Select the Settings > Protection > Elements > Group 1 > Load Encroachment menu to
open the load encroachment configuration window.
$&'5
$
Q
J
O
H
$
Q
J
O
H
²5HDFK
5HDFK
/RDG
HQFURDFKPHQW
RSHUDWH
5
;
/RDG
HQFURDFKPHQW
RSHUDWH
