LINE DISTANCE PROTECTION SYSTEM – INSTRUCTION MANUAL
ORDER CODES CHAPTER 2: PRODUCT DESCRIPTION
Order codes
The order code indicates the product options applicable.
The D90
Plus
is available as a 19-inch horizontal rack-mount unit. It consists of a number of
required and optional modules. Module options are specified at the time of ordering.
NOTE
NOTE:
The order codes shown are subject to change without notice. See the ordering page at
http://www.gedigitalenergy.com/multilin/order.htm for the latest options.
Figure 13: Order codes
Specifications
Specifications are subject to change without notice.
Protection specifications
AUTORECLOSURE
Applications: .........................................................two breakers
Tripping schemes: .............................................. single-pole and three-pole
Reclose attempts:............................................... up to 4 before lockout
Reclosing mode:..................................................selectable
Breaker sequence: .............................................selectable
D90P – * – * – * – * – ** – ** – * – * – * – * – * – * – * – * – * – * – ** – * D90Plus Line Distance Protection System
Base
Front panel
interface
A | | | | | | | | | | | | | | | | | Annunciator
H | | | | | | | | | | | | | | | | | Annunciator and HMI
Language E
Protection S | | | | | | | | | | | | | | | Three-pole distance protection
E | | | | | | | | | | | | | | | Three-pole distance protection and protection FlexLogic
A | | | | | | | | | | | | | | | Single-pole/three-pole sub-cycle distance protection, series
Automation S
E
Communications 01 | | | | | | | | | | | | | Modbus TCP/IP, DNP 3.0 serial, and serial Modbus
02 | | | | | | | | | | | | | Modbus TCP/IP and IEC 61850
03 | | | | | | | | | | | | | Modbus TCP/IP, IEC 61850, and DNP 3.0 TCP/IP
04 | | | | | | | | | | | | |
Modbus TCP/IP, IEC 61850, and IEC 60870-5-104
Metering
S
P
L
U
Digital fault recorder S | | | | | | | | | | | Transient recorder and sequence of events recorder
D | | | | | | | | | | | Transient recorder, sequence of even ts recorder, and disturbance detector
Equipment manager S
C
Harsh-environment coating X | | | | | | | | |
Power supply H
Inter-relay communications X | | | | | | | Reserved
B | | | | | | | G.703, 64/128 kbps, two channels
C | | | | | | | RS422, 64/128 kbps, two channels, two clock inputs
D | | | | | | | 850 nm, 64/128 kbps, ST multi-mode laser, two channels with DDMI
Communications X |||| | |No communications module
A||||||Dual ST fiber and copper module
Input/output modules X X X X | X No input/output modules
A A A A | A 8 inputs, 4 form-A outputs with voltage and current monitoring
B B B B | B 8 inputs, 4 solid-state outputs with voltage and current monitoring
C C C C | C 8 inputs, 4 form-A outputs
D D D D | D 4 inputs, 8 form-A outputs
E E E E | E 23 inputs
F F F F | F 12 form-A outputs
AC modules
| || | ||||||||||| | |
Base unit
|| | ||||||||||| | |English
| ||||||||||| | |Breaker control and synchrocheck
| ||||||||||| | |
Breaker control, synchrocheck, and automation controller
||||||||| | |
Basic metering
|
||||||||| | |
Basic metering and synchrophasors
|
||||||||| | |
Basic metering and data logger
|
||||||||| | |
Basic metering, synchrophasors, and data logger
|
|||||||| | |
Circuit breaker, communications statistics, and batter y monitor
|||||||| | |Circuit breaker, comms statistics, battery monitor, breaker monitor
|||||| | |High (88 to 275 V AC; 80 to 300 V DC)
02 5 VT and 7 CT (1 Amp current)
01 5 VT and 7 CT (5 Amp current)
None
|||||||||
C
Harsh-environment conformal coating
|
D90P
| | | | | | | | | | | | | | | compensation, and protection FlexLogic
870787A6.cdr
A2 | | | | | | | | | | | | | Modbus TCP/IP, IEC 61850, and PRP
A3 | | | | | | | | | | | | | Modbus TCP/IP, IEC 61850, DNP 3.0 TCP/IP, and PRP
A4 | | | | | | | | | | | | |
Modbus TCP/IP, IEC 61850, IEC 60870-5-104, and PRP
