GE HEALTHCARE

DIRECTION 5394152, Revision 5

LOGIQ™ P6/P6 PRO SERVICE MANUAL

Page 5-22 Section 5-1 - Overview

5-6-5 Fans

There are 10 fans for ventilation in the system as below

a.) DTRX64II Assy: 2 fans in each assy.

b.) SYSCONML: 1 fan

c.) APS II: 2 fans

d.) NESTBOX top: 2 fans

e.) TRANBOX: 1 fan

Figure 5-22 Location of Fans

(d) Cooling FAN Assy for NEST Cooling

(a) Cooling Fan on L2 SYSCON II(SYSCONML)

(b) Cooling Fans on APS

(e) TRANS BOX FAN
