GE HEALTHCARE
DIRECTION 5394152, Revision 5
LOGIQ™ P6/P6 PRO SERVICE MANUAL
Page 8-154 Section 8-7 - Mechanical Option Installation instruction
8-7-1 Endo Probe Holder Installation
1.) Check out the 2 screw holes to be used to install Endo Probe Holder.
2.) Install Endo Probe holder on the bottom side of the Cable Arm Hook by screwing 2
screws(2159634, BH M4x10 WHT).
Figure 8-230 Endo Probe Holder Installation
Figure 8-231 Endo Probe Holder

GE LOGIQ P6 Series Specifications

General

Power Supply	100-240 VAC, 50/60 Hz
Imaging Modes	B-Mode, M-Mode, Color Doppler, Power Doppler
Applications	Vascular, Musculoskeletal
Operating Temperature	10°C to 40°C
Display	15-inch LCD
Relative Humidity	20% to 80% (non-condensing)
