LOGIQ™ P6/P6 PRO SERVICE MANUAL
Chapter 7 - Page 7-29
7-9-3 System Does Not Boot
Figure 7-15 System does not Boot (contd.)
System doesn’t boot! (cont’d)
YES
Check;
1.) AC Power
2.) AC Transformer
Go on to the next page.
NO
Do the fans start to run?
Check/replace the PM SOM/CM
SOM module.
YES
NO
Is the SOM module starting
to display start-up screens
on the monitor?
Is the LOGIQ starting
display shown on the
monitor?
Turn off the power, wait a few
seconds, and try to turn on the
power again.
NO

GE LOGIQ P6 Series Specifications

General

Power Supply	100-240 VAC, 50/60 Hz
Imaging Modes	B-Mode, M-Mode, Color Doppler, Power Doppler
Applications	Vascular, Musculoskeletal
Operating Temperature	10°C to 40°C
Display	15-inch LCD
Relative Humidity	20% to 80% (non-condensing)
