Page 8-190 Section 8-7 - Mechanical Option Installation instruction

8-7-18 BT11 Drawer Option Installation

1.) This section describes the installation procedure of the drawer option.

2.) Assemble the BW PRINTER to DRAWER FIX BRKT with screwing 4 screws (2306562, FH M3X6).

3.) Assemble the BT11 DRAWER to DRAWER FIX BRKT using 2 hooks.

Figure 8-313 BT11 Drawer Option Installation

Figure 8-314 BT11 Drawer Option Installation
