GE LOGIQ P6 Series User Manual

GE HEALTHCARE
DIRECTION 5394152, Revision 5
LOGIQ™ P6/P6 PRO SERVICE MANUAL
Chapter 8 - Page 8-79
8-2-33 Front Caster / Rear Caster
NOTE: Both Front Casters and Rear Casters are swivel type in LOGIQ™ P6/P6 Pro.
8-2-33-1 Tools
• Common Phillips screwdrivers
• Allen/Unbraco wrench
8-2-33-2 Preparations
• Shut down the system and switch off the main breaker.
8-2-33-3 Removal procedure
1.) Unscrew 8 screws (1A-8A) to remove the front caster.
2.) Unscrew 8 screws (1-8) to remove the rear caster.
Figure 8-119 Casters

GE LOGIQ P6 Series Specifications

General

Power Supply	100-240 VAC, 50/60 Hz
Imaging Modes	B-Mode, M-Mode, Color Doppler, Power Doppler
Applications	Vascular, Musculoskeletal
Operating Temperature	10°C to 40°C
Display	15-inch LCD
Relative Humidity	20% to 80% (non-condensing)
