GE HEALTHCARE
DIRECTION 5394152, Revision 5
LOGIQ™ P6/P6 PRO SERVICE MANUAL
Page 8-88 Section 8-2 - DISASSEMBLY/RE-ASSEMBLY
8-2-40-3 Removal procedure (cont’d)
7.) Unscrew 8 screws to remove the bracket from the DVD Assy.
8.) Perform the following functional tests. If all are successful, include the debrief script provided below.
8-2-40-4 Mounting Procedure
Install the new parts in the reverse order of removal.
Figure 8-130 Unscrew 8screws and remove the DVD Drive from the bracket
Table 8-41 Functional Tests
Service Manual
Section Functional Test / Diagnostic Test Debrief Script
Section 4-3-1
Power On/Boot Up
“Service Manual, Direction
5394152, Rev 1+, Section 8-2-40. Equipment
passed all required tests and is ready for use. “
Section 4-3-2
Power Off / Shutdown
To Next Page
