10-6-2 GEMS Leakage Current Limits
The following limits are summarized for NFPA 99 (For USA) and IEC 60601-1 Medical Equipment
Safety Standards. These limits are GEMS standards and in some cases are lower than the above
standards listed.
NOTE: *Mains Applied refers to
the sink leakage test where mains (supply) voltage is applied to the
part to determine the amount of current that w
ill pass (or sink
) to ground if a patient contacted
mains volt
age.
The following tests are performed at the factory and should be performed at the site. These tests are:
grounding continuity, chassis leakage current, probe leakage current, and ECG leakage current. All
measurements are made with an electrical safety analyzer Model 600/600E built by Dale Technology
Corporation or equivalent device.
Table 10-14 Chassis Leakage Current Limits—Accessible Metal Surfaces
Country Normal Condition Open Ground Reverse Polarity Open Neutral
USA
N/A
0.3 mA 0.3 mA N/A
Other
0.1 mA
0.5 mA 0.5 mA 0.5 mA
Table 10-15 Type BF Applied Part Leakage Current Limits - Non-Conductive (Floating) Surface
and Cavity Probes
Country
Normal
Condition
Open Ground Reverse Polarity Open Neutral *Mains Applied
USA
0.05 mA
0.05 mA 0.05 mA 0.05 mA N/A
Other
0.1 mA
0.5 mA 0.5 mA 0.5 mA 5.0 mA
Table 10-16 Type CF Applied Part Leakage Current Limits - Surgical Probes and ECG
Connections
Country
Normal
Condition
Open Ground Reverse Polarity Open Neutral *Mains Applied
USA
0.01 mA
0.05mA 0.05 mA N/A 0.025 mA
Other
0.01 mA
0.05 mA 0.05 mA 0.05 mA 0.05 mA
